Micro Cable Carriers · 7 Series

7 Series Bridge-type cable carrier, inner height 7 mm, inner width 10 mm

WSL02-7-10 is a CNWSL Micro Cable Carriers 7 Series carrier with 7 mm inner height, 10 mm inner width, PA6+GF30 reinforced nylon, and bend radii R15.

WSL02-7-10 7seriesmain view

Specifications

Model code
WSL02-7-10
Inner height (H)
7 mm
Inner width (B)
10 mm
Opening type
Bridge-type
Material
PA6+GF30 reinforced nylon
Connector
WSL02-7-10C
Download drawing (PDF)Back to series list

Available bend radii

The same size can be ordered with different bend radii (R). Length and travel can be customized to your duty cycle.

Bend radiusCode exampleNotes
R15WSL02-7-10-R15Compact spaces

Features

  • Bridge-type design for industrial cable protection
  • Inner height 7 mm / inner width 10 mm
  • Bend radii R15
  • Material PA6+GF30 reinforced nylon
  • Matching connector WSL02-7-10C

7 Series — Other sizes in this series

Request a quote

Tell us your machine type, travel and bend-radius needs—we will reply with pricing promptly.
